The production process of wood pellet machine includes:
1. Casting wood pellet machine bearings and large shafts. The bearing chamber and large shaft chamber of the wood pellet machine are cast after melting No. 40 steel, and then rough turning according to the drawings, and then heat treatment, in the process of heat treatment, the wood pellet machine and bearing chamber and large shaft will be deformed, and finally the fine turning.
2. Production of wood pellet machine ring die and press roller assembly. The ring die of the wood pellet machine is made of 20CrMoTi material, and the production cycle takes about 10 days. The press roller assembly material of the wood pellet machine is 65 manganese steel, and the production cycle takes about 7 days.
3. The compression chamber of the welding wood pellet machine is made of 201 stainless steel. Because the wood pellet machine in the process of pressing wood pellets will evaporate 3-5% of the water vapor, the use of stainless steel compression chamber can greatly reduce the risk of rust.
4. Assemble wood pellet machine reducer. The gear reducer of the wood pellet machine is equipped with 4 stages of gear, and the 1470 RPM motor is slowed down to 80 RPM through the gear reducer. Pay attention to the gap and fit between gears during assembly.
5. Assemble the wood pellet machine. After the production of the various parts of the wood pellet machine, each part is assembled together according to the drawings, and the trial run is completed. Judge the state of the wood pellet machine by observing the current, voltage, the sound of the machine in operation and whether the machine has vibration.
Every wood pellet spare part will affect the quality of the machine, choosing a professional manufacturer is the guarantee of efficient production.
