The overall structure of the peanut shell pellet machine is the same as that of the conventional wood pellet machine, but there are three points that are different.

First: the ring die of the peanut shell pellet machine is different. The compression ratio of the ring die of the configured wood pellet machine is 5.8, and the shape of the ring die is step mouth. The reason is that the peanut shell will contain a lot of dust and impurities, which requires greater pressure to extrude during the production process, and the ring die of the step mouth is more wear-resistant than the mold of the horn mouth, and the service life is extended.
Second: The material of the press roller of the peanut shell pellet machine is welded, and the reason is also to extend the life of the press roller of the peanut shell pellet machine.
Third: The reducer wheelbase of the peanut shell pellet machine is 1048mm, which is 128mm more than the wheelbase of the conventional model wood pellet machine. The reason is that by increasing the torque and increasing the pressure of the pressure, the peanut shell is more easily extruded into biomass pellet.
